Drying silos after cleaning
Dehumidifying storage containers quickly and safely
Before a different type of bulk material can be stored in the same silo (or another storage or transport container) it is cleaned with water. To be able to reuse these containers as soon as possible, we recommend the application of adsorption dryers of the TTR series.
After the cleaning of storage containers and silos you have to count on them to be fully dried for new bulk material to be protected against moisture from the beginning. And since drying can be effected in a quick and economical manner, we advise decision makers from the chemical and pharmaceutical industry to consider our high-performance dryers of the TTR series.
Adsorption dryer TTR 1400 dries every silo
With their two separate air flow ducts (TTR Trisorp Dual principle of operation) all adsorption dryers of this series are characterized by a particularly simple adjustability. Furthermore, with the internal heat recovery as well as the high level of resilience and performance of the special rotors they rank among the most economical adsorption dryers of their kind. The TTR series comprises both stationary and mobile adsorption dryers. Particularly a mobile version of the TTR 1400 with transport frame is optimally suited for the dehumidification of silos in the chemical and pharmaceutical industry. This powerful adsorption dryer impresses with a dehumidification performance of approx. 177 kg in 24 hours at 20 °C and a relative humidity of 60 per cent. It dehumidifies an air volume of up to 1,800 m³/h. It is also available as stainless steel version.
Fan hoses and measurement technology to complement the system
To match this high-performance adsorption dryer, the air transport hoses should also be designed for full-scale industrial usage. Trust the brand quality of high-class, spiral-reinforced fan hoses of the Tronect® series.
Several hand-held measuring devices such as thermohygrometers and data loggers like the innovative DL200X complete the dehumidification concept in the silo and so enable constant monitoring of the drying process.
Drafting and test run: make use of our industrial services
For the chemical industry and pharmaceutical production the Trotec Group not only supplies devices for dehumidification related to hygroscopic bulk material. In consultation with you we also develop the dehumidification concept for your transport containers and silos. We further provide mobile dehumidifiers to test the concept beforehand in trial operation. Only after measurements have proved that drying can be effected quickly and without fail will your final solution be launched.
Further solutions for the chemical industry
Further solutions for the pharmaceutical industry
Temporary demand? Rental appliances for every requirement
You need mobile adsorption dryers for the temporary drying of silos after cleaning? Just rent them, then. In our TKL rental portal you can find devices of all performance classes at a favourable price!
Upon request, we will readily produce tailor-made desiccant dehumidifiers as special models “made in Germany” perfectly geared to your needs, e.g.:
- TTR industrial desiccant dehumidifiers with hygienic design
- TTR industrial desiccant dehumidifiers for PWIS-free dry air
- TTR industrial desiccant dehumidifiers with extremely low dew point
Makes use of the possibility of having special models with tailored components for your individual needs planned, designed and manufactured in close consultation with our specialists.
